1. Mobile Four Bin Feeder 6 cum fitted with variable speed motors and Gear Box. Oversize mesh on the cold feeder.
2. Single Deck Vibratory Screen for removal of oversize material. Mounted with the coldfeeder
3. Mobile Drying drum mounted on forged tyre rings with 4 x trunnion driven by a common single motor by chain drive for easy maintenance
4. Mobile Bag Filter system (Common with Drum)
5. Slinger Conveyor for feeding cold aggregates intro the dryer drum
6. Cerawool insulation and aluminium sheet cladded dryer drum fitted with burner
7. Continuous Pug Mill Mixer with a retention time of 12 secs to ensure good homogenous mix discharge to gob hopper. The unit is mounted between the Drum and bag filter and is moved up during transport by hydraulic
8. Hot conveyor fitted with gob hopper for discharging hot mix material onto tipper truck. Transported together with the drum section
9. Mineral Filler wiegher fitted with rotary valve and blower
10. Glass wool insulated bitumen (asphalt) tank fitted with burner and bitumen pump station capacity 30 tons fitted in a container
11. Hot oil circulation system with jacketed pipelines to prevent clogging of bitumen pipelines and intermediate storage tank. The complete unit is fitted in shippable container common to fuel storage tank
12. Fuel Storage tank capacity 5 KL with internal heating coil
13. Fully insulated control cabin fitted with air conditioner and micro processor based electronic control panel having feather touch controls, totalizer and printer (Mobile mounted underneath the cold feeder
14. Cladding sheets to protect the complete plant.
